Hydraulic Wheelchair Accessible Platform Lift – PlatinumLift®

    $1,200.00

    BENEFIT

    • Handles loads up to 360 kg, making it suitable for both wheelchair users and caregivers

    • Anti-slip full-size platform with an automatic safety flap for added security

    • Available in various platform dimensions to suit a range of vehicle types

    • Equipped with a manual emergency pump to ensure dependable backup operation

    • Powered by either a 12V or 24V electrical system for flexible integration

    Category:

      PlatinumLift® Hydraulic Wheelchair Platform Lift

      The PlatinumLift® Hydraulic Wheelchair Platform Lift is a dependable mobility solution designed to assist individuals with limited mobility in entering and exiting vehicles with ease. Built with a rugged dual-arm structure, anti-slip platform, and multiple safety mechanisms, it provides smooth, secure operation. It’s ideal for use in specially equipped vehicles to enhance overall accessibility.

      Key Features

      • Full-length, anti-slip platform with a fixed grid surface for added safety and durability.

      • Dual-arm hydraulic design ensures steady and powerful lifting performance.

      • Powered by an electro-hydraulic system operating two hydraulic cylinders.

      • Comes with a spiral cable hand control for effortless, automated operation.

      • Offered in four platform dimensions: 115×80 cm, 130×80 cm, 140×80 cm, and 140×90 cm.

      • Compatible with a variety of specially adapted vehicles.

      • Includes a manual emergency pump for backup use during power loss or system failure.

      • Battery master switch allows quick and easy power cut-off.

      • Built-in safety flap secures the wheelchair during operation to prevent accidental movement.

      • Anti-tilt system and dual microswitches enhance operational stability and safety.

      • Wireless remote control kit included for added user convenience.

      • Vertical columns feature flashing LED lights to increase visibility.

      • Auto-deploying bridge plate provides a secure link between the lift and the vehicle.

      Technical Specifications

      Model Max Capacity Weight Power Supply Platform Size Lifting Height Speed Up Speed Down Emergency Pump
      BBI 115.80 360 kg 125 kg 12V 115 x 80 cm 100 cm 5 m/min 4 m/min Yes
      BBI 130.80 360 kg 130 kg 12V 130 x 80 cm 100 cm 5 m/min 4 m/min Yes
      BBI 140.80 360 kg 140 kg 12V 140 x 80 cm 100 cm 5 m/min 4 m/min Yes
      BBI 140.90 360 kg 150 kg 12V–24V 140 x 90 cm 100 cm 5 m/min 4 m/min Yes

      Advantages

      • Improved Accessibility: Allows wheelchair users to enter vehicles with ease.

      • Tailored Options: Various platform sizes provide a customizable fit for different vehicle types.

      • Maximum Safety: Multiple integrated safety features ensure reliable and secure lifting.

      • Easy Operation: Remote and manual control options make usage simple and efficient.
